内径(mm) |
夹布层数 |
螺旋钢丝直径(mm) |
管接头长度(mm) |
胶管长度 |
|||
|
公称尺寸 |
公差 |
尺寸 |
公差 |
尺寸 |
公差 |
||
|
38 |
1.2 |
23 |
2.0 |
75 |
10 |
10 |
150 |
|
51 |
1.2 |
34 |
2.6 |
100 |
15 |
10 |
150 |
|
64 |
1.5 |
34 |
2.6 |
100 |
15 |
10 |
150 |
|
76 |
1.5 |
45 |
2.6 |
100 |
15 |
10 |
150 |
|
89 |
1.5 |
45 |
3.2 |
100 |
15 |
10 |
150 |
|
102 |
2.0 |
45 |
3.2 |
125 |
20 |
10 |
150 |
|
127 |
2.0 |
5 6 |
3.2 |
125 |
20 |
10 |
150 |
|
152 |
2.0 |
56 |
4.0 |
150 |
20 |
10 |
150 |
|
203 |
2.5 |
67 |
5.0 |
200 |
25 |
10 |
150 |
|
254 |
2.5 |
78 |
5.0 |
200 |
25 |
10 |
150 |
|
305 |
2.5 |
78 |
5.0 |
250 |
25 |
10 |
150 |
